Product Description:
Large cooling capacity industrial chiller CW-8000 ensures precise temperature control in analytical, industrial, medical and laboratory applications. It cools in a temperature range of 5°C-35 °C and achieves stability of ±1°C while providing a 42000W large cooling capacity. With a robust design, air cooled water chiller CW-8000 ensures continuous and reliable operation. The digital control panel is easy to read and provides multiple alarms and safety functions.
Industrial water cooler CW-8000 is equipped with high-performance compressor and efficient evaporator to achieve high energy efficiency, so the operating cost can be significantly reduced. Thanks to the supported Modbus485 function, this recirculating water chiller is available for remote operation - monitoring the working status and modifying the parameters of the chiller. 50Hz/60Hz and 380V/415V/460V are available.
Features:
* Cooling Capacity: 42000W
* Active cooling
* Temperature stability: ±1°C
* Temperature control range: 5°C ~35°C
* Refrigerant: R-410a
* Intelligent temperature controller
* Multiple alarm functions
* High reliability, energy efficiency and durability
* Easy maintenance and mobility
* Available in 380V, 415V or 460V
Technical Parameters:
| Model |
CW-8000EN |
CW-8000FN |
| Voltage |
AC 3P 380V |
AC 3P 380V |
| Frequency |
50Hz |
60Hz |
| Current |
6.4~40.1A |
8.1~38.2A |
| Max. power consumption |
21.36kW |
21.12kW |
Compressor power |
12.16kW |
11.2kW |
| 16.3HP |
15.01HP |
Nominal cooling capacity |
143304Btu/h |
| 42kW |
| 36111Kcal/h |
| Refrigerant |
R-410a |
| Precision |
±1℃ |
| Reducer |
Capillary |
| Pump power |
2.2kW |
3kW |
| Tank capacity |
210L |
| Inlet and outlet |
Rp1-1/2" |
| Max. pump pressure |
7.5bar |
5.8bar |
| Max. pump flow |
200L/min |
| N.W. |
438Kg |
| G.W. |
513Kg |
| Dimension |
190X108X140cm (L X W X H) |
| Package dimension |
202X123X162cm (L X W X H) |
The working current can be different under different working conditions. The above information is for reference only. Please subject to the actual delivered product.
|
|
|
Applications:
* Laboratory equipment (rotary evaporator, vacuum system)
* Analytical equipment (spectrometer, bio analyzes, water sampler)
* Medical diagnostic equipment(MRI, X-ray)
* Plastic molding machines
* Printing machine
* Furnace
* Welding machine
* Packaging machinery
* Plasma etching machine
* UV curing machine
* Gas generators
