Industrial Chiller Unit CW-7500 18000W Cooling Capacity Constant & Intelligent Temperature Control
Product Description:
TEYU industrial chiller CW-7500 offers a cooling capacity of up to 18000W, being the ideal cooling equipment for various industrial, analytical, laboratory and medical applications. An intelligent temperature controller working in English provides you clear insights to the operating condition of the chiller. The refrigerant circuit system adopts solenoid valve bypass technology to avoid frequent start and stop of the compressor to prolong its service life.
All of the components of industrial chiller CW-7500 are manufactured in high quality standards to ensure reliable operation while the whole air cooled chiller complies with CE, RoHS and REACH qualifications. Multiple alarms are designed to provide full protection. An RS485 interface is integrated in the temperature controller for PC connection. Available in various power specifications and provide 2 years warranty.
Features:
* Cooling Capacity: 18000W
* Active cooling
* Temperature stability: ±1°C
* Temperature control range: 5°C ~35°C
* Refrigerant: R-410a
* Intelligent temperature controller
* Multiple alarm functions
* RS-485 Modbus communication function
* High reliability, energy efficiency and durability
* Easy maintenance and mobility
* Available in 380V, 415V or 460V
Technical Parameters:
| Model |
CW-7500EN |
CW-7500FN |
| Voltage |
AC 3P 380V |
AC 3P 380V |
| Frequency |
50Hz |
60Hz |
| Current |
2.1~18.9A |
2.1~16.7A |
| Max. power consumption |
8.86kW |
8.47kW |
Compressor power |
5.41kW |
5.12kW |
| 7.25HP |
6.86HP |
Nominal cooling capacity |
61416Btu/h |
| 18kW |
| 15476Kcal/h |
| Refrigerant |
R-410a |
| Precision |
±1℃ |
| Reducer |
Capillary |
| Pump power |
1.1kW |
1kW |
| Tank capacity |
70L |
| Inlet and outlet |
Rp1" |
| Max. pump pressure |
6.15bar |
5.9bar |
| Max. pump flow |
117L/min |
130L/min |
| N.W. |
160Kg |
| G.W. |
182Kg |
| Dimension |
105 X 71 X 133 cm (LX W X H) |
| Package dimension |
112 X 82 X 150 cm (LX W X H) |
The working current can be different under different working conditions. The above information is for reference only. Please subject to the actual delivered product.
|
Applications:
* Laboratory equipment (rotary evaporator, vacuum system)
* Analytical equipment (spectrometer, bio analyzes, water sampler)
* Medical diagnostic equipment(MRI, X-ray)
* Plastic molding machines
* Printing machine
* Furnace
* Welding machine
* Packaging machinery
* Plasma etching machine
* UV curing machine
* Gas generators
