Industrial Process Water Chiller Cooling System CW-6000 with 3140W Cooling Capacity
Product Description:
TEYU water chiller cooling system CW-6000 developed by TEYU chiller manufacturer is programmed to perform high quality refrigeration for a wide variety of industrial, medical, analytical and laboratory applications. Proven 24/7 reliability, extremely high energy efficiency and durability set us apart in the refrigeration industry.
Industrial process water chiller CW 6000 offers 3140W cooling capacity while maintaining the temperature fluctuation at ±0.5°C. CW-6000 chiller incorporates a high quality compressor for optimum performance and less energy consumption. A user-friendly control panel allows you to set your desired temperature as needed or leave the water temperature automatically adjusting itself in the range of 5°C to 35°C.
Features:
* Cooling Capacity: 3140W
* Active cooling
* Temperature stability: ±0.5°C
* Temperature control range: 5°C ~35°C
* Refrigerant: R-410a
* User-friendly temperature controller
* Integrated alarm functions
* Back mounted water fill port and easy-to-read water level check
* Multiple power specifications
* High reliability, energy efficiency and durability
* Simple setup and operation
Technical Parameters:
| Model |
CW-6000AH |
CW-6000BH |
CW-6000DH |
CW-6000AI |
CW-6000BI |
CW-6000DI |
CW-6000AN |
CW-6000BN |
CW-6000DN |
| Voltage |
AC 1P 220-240V |
AC 1P 220-240V |
AC 1P 110V |
AC 1P 220-240V |
AC 1P 220-240V |
AC 1P 110V |
AC 1P 220-240V |
AC 1P 220-240V |
AC 1P 110V |
| Frequency |
50Hz |
60Hz |
60Hz |
50Hz |
60Hz |
60Hz |
50Hz |
60Hz |
60Hz |
| Current |
0.5~5.2A |
0.5~5.2A |
0.5~8.9A |
0.4~5.1A |
0.4~4.8A |
0.4~8.8A |
2.3~7A |
2.1~6.6A |
6~14.4A |
| Max. power consumption |
1.08kW |
1.04kW |
0.96kW |
1.12kW |
1.08kW |
1kW |
1.4kW |
1.36kW |
1.51kW |
| Compressor power |
0.94kW |
0.88kW |
0.79kW |
0.94kW |
0.88kW |
0.79kW |
0.94kW |
0.88kW |
0.79kW |
| 1.26HP |
1.17HP |
1.06HP |
1.26HP |
1.17HP |
1.06HP |
1.26HP |
1.17HP |
1.06HP |
| Nominal cooling capacity |
10713Btu/h |
| 3.14kW |
| 2699Kcal/h |
| Pump power |
0.05kW |
0.09kW |
0.37kW |
0.6kW |
| Max. pump pressure |
1.2bar |
2.5bar |
2.7bar |
4bar |
| Max. pump flow |
13L/min |
15L/min |
75L/min |
| Refrigerant |
R-410a |
| Precision |
±0.5℃ |
| Reducer |
Capillary |
| Tank capacity |
10L |
| Inlet and outlet |
Rp1/2" |
| N.W |
35Kg |
36Kg |
43Kg |
| G.W |
44Kg |
45Kg |
52Kg |
| Dimension |
59X38X74cm (L X W X H) |
| Package dimension |
66X48X92cm (L X W X H) |
|
The working current can be different under different working conditions. The above information is for reference only. Please subject to the actual delivered product.
Applications:
* Laboratory equipment (rotary evaporator, vacuum system)
* Analytical equipment (spectrometer, bio analyzes, water sampler)
* Medical diagnostic equipment(MRI, X-ray)
* Machine tool (high speed spindle)
* Plastic molding machines
* Printing machine
* Furnace
* Welding machine
* Packaging machinery
* Plasma etching machine
* UV curing machine
* Gas generators
* Helium compressor (cryo compressors)
