Product Description:
TEYU industrial water chiller system CW-7800 can handle cooling requirements in a wide variety of industrial, analytical,medical and laboratory applications. It features proven reliability in 24/7 operation with excellent refrigeration performance, thanks to the high cooling capacity of 26000W and the high performance compressor. The unique evaporator-in-tank configuration has been specifically designed for process cooling applications.
Large cooling capacity water chiller CW-7800 allows high water flow rates with low pressure drops and ensures reliable operation even in demanding applications. Multiple alarms are designed to provide full protection. The removable air filters (filter gauzes) allow easy routine maintenance while an RS485 interface is integrated in the temperature controller for PC connection. CW-7800 chiller is an ideal industrial cooling tool for your high-power processing equipment.
Features:
* Cooling Capacity: 26kW
* Active cooling
* Temperature stability: ±1°C
* Temperature control range: 5°C ~35°C
* Refrigerant: R-410a
* Intelligent temperature controller
* Multiple alarm functions
* RS-485 Modbus communication function
* High reliability, energy efficiency and durability
* Easy maintenance and mobility
* Available in 380V,415V or 460V
Technical Parameters:
| Model |
CW-7800EN |
CW-7800FN |
| Voltage |
AC 3P 380V |
AC 3P 380V |
| Frequency |
50Hz |
60Hz |
| Current |
2.1~24.5A |
2.1~22.7A |
| Max. power consumption |
14.06kW |
14.2kW |
Compressor power |
8.26kW |
8.5kW |
| 11.07HP |
11.39HP |
Nominal cooling capacity |
88712Btu/h |
| 26kW |
| 22354Kcal/h |
| Refrigerant |
R-410a |
| Precision |
±1℃ |
| Reducer |
Capillary |
| Pump power |
1.1kW |
1kW |
| Tank capacity |
170L |
| Inlet and outlet |
Rp1" |
| Max. pump pressure |
6.15bar |
5.9bar |
| Max. pump flow |
117L/min |
130L/min |
| N.W |
277Kg |
270Kg |
| G.W |
317Kg |
310Kg |
| Dimension |
155x80x135cm (L x W x H) |
| Package dimension |
170X93X152cm (L x W x H) |
The working current can be different under different working conditions. The above information is for reference only. Please subject to the actual delivered product.
|
Applications:
* Laboratory equipment (rotary evaporator, vacuum system)
* Analytical equipment (spectrometer, bio analyzes, water sampler)
* Medical diagnostic equipment(MRI, X-ray)
* Plastic molding machines
* Printing machine
* Furnace
* Welding machine
* Packaging machinery
* Plasma etching machine
* UV curing machine
* Gas generators
